$180.29$180.29 -
Baumer
FPDK 14N5101/S14
11001185
Retroreflective Sensor, Standard, Pulsed Red LED, 10-30VDC, 7m Actual Range Sb, 7.2m Nominal Range Sn, NPN, Light/Dark Operate, M12 4-Pin Connector, 43 x 14.8 x 31mm (HWD), Plastic (ASA, MABS) Housing, PMMA Optics, -20° to +65°C, IP67
$235.09$235.09 -
$272.69$272.69 -
Baumer
FGUM 050P6901/S35A
10162164
Fork Sensor, Thru-Beam, Pulsed Red LED, 10-35VDC, Teach-in (Button/External), PNP, Light/Dark Operate, M8 Connector, Die-Cast Zinc, -10 to +60°C, IP67
$552.60$552.60 -
Baumer
O500.ER-PV1T.72O
11128075
Thru-Beam Sensor, Receiver, 10-30VDC, 25m Actual Range Sb, PNP, qTeach, Light/Dark Operate, M12 4-Pin Connector, Plastic Housing, PMMA Front (Optics), 45 x 18 x 32mm (HWD), -25 to 60°C Operating Temperature, IP67
$106.60$106.60 -
Baumer
O300.RL-NV1T.72N
11172801
Retroreflective Sensor, Polarization Filter, Pulsed Red Laser Diode, Laser Class 1, 11-30VDC, 5m Actual Range Sb, qTeach, NPN Complementary, Light/Dark Operate, M8 4-Pin Connector, 12.9 x 32.3 x 23mm (WxHxD), Plastic (ASA/PMMA), -10 to +60°C, IP67
$302.20$302.20 -
Baumer
OM70-P1000.HV0700.VI
11200091
High Performance Laser Distance Sensor, 100-1000mmMeasuring Distance Sd, 700mm Sweet Spot, OM70 Laser Point, Touch Display, RS485, 15-28VDC, Analog and RS485, IP67, 74 x 26 x 55mm (HWD)
$3,479.29$3,479.29 -
Baumer
O300.SP-NV1T.72CU
11120126
SmartReflect Light Barrier, PinPoint LED, 10-30VDC, 30-300mm Background Position Sde, qTeach, NPN Complementary, Light/Dark Operate, 2m 4-Pin Cable, 12.9 x 32.3 x 23mm (WxHxD), Plastic (ASA/PMMA), -25 to +60°C, IP67
$284.60$284.60 -
Baumer
O500.SP-PV1T.72CU/T003
11135867
SmartReflect Light Barrier, 10-30VDC, 60-600mm Background Position Side, Pulsed PinPoint LED, 630 nm, PNP, qTeach/1-Step Teach-In, Light/Dark Operate, 2m 4-Pin Cable, Plastic Housing, PMMA Optics, 45 x 18 x 32mm (HWD), -25 to 60°C Operating
$302.20$302.20 -
Baumer
OT300.SL-PDPVT.72CU
11250345
SmartReflect Light Barrier, Pulsed Red Laser Diode, Laser Class 1, 12-30VDC, PNP, Dark Operate, 2m 4-Pin Cable, 12.9 x 32.3 x 23mm (WxHxD), Plastic (ASA/PMMA), -20 to +50°C, IP67
$339.20$339.20 -
$325.09$325.09 -
Baumer
OM70-L0600.HH0500.EK
11216515
High Performance Laser Distance Sensor, 100-600mm Measuring Distance Sd, 500mm Sweet Spot, OM70 Laser Line Basic, Webserver, Ethernet TCP/IP, 15-28VDC, Analog and Digital, IP67, 74 x 26 x 55mm (HWD)
$3,818.80$3,818.80
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
Additional Sensor Categories:
Proximity | Ultrasonic | Pressure | Temperature | Level | Tilt
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
