Baumer
FPDM 16N5101/S14
Photoelectric Retro-Reflective Sensor, 7.3 Meter Range, 660 nm Wave Length, Polarized Filter, Pulsed Red LED, PNP, Connector M12 4 Pin, IP67
$414.49$414.49 -
Baumer
FPDM 12N3401/S35A
Photoelectric Retro-Reflective Sensor, 5 Meter Range, 600 nm Wave Length, NPN, Polarized Filter, Pulsed Red LED, Connector M8 4 Pin, -25...65 ℃, IP67
$388.29$388.29 -
Baumer
FPDM 16N5101
Photoelectric Retro-Reflective Sensor, 7.3 Meter Range, 660 nm Wave Length, Polarized Filter, NPN, Pulsed Red LED, IP67
$426.80$426.80 -
Baumer
FPDM 12P5101
Retro-Reflective Sensor, 5 Meter Range, 660 nm Wave Length, Pulsed Red LED, Polarized Filter, PNP, Cable Length 2 Meter 4 Pin, IP67
$362.09$362.09 -
Baumer
11001315
Photoelectric Sensor, Retro-Reflective, 10m Sensing Range, PNP, M8 4-Pin Connector, IP67
$966.60$966.60 -
Baumer
11001311
Photoelectric Sensor, Retro-Reflective, 4.5m Sensing Range, PNP, M8 4-Pin Connector, IP67
$1,151.49$1,151.49 -
Leuze
50137158
Polarized Retroreflective Sensor, 10-30VDC, Switching Output 1: Push-Pull Light PNP/Dark NPN and Output 2: Push-Pull Dark PNP/Light NPN, 0.2 Black PUR Cable with M12 Male 4-Pin A-Coded Metal Connector, 11.4 x 34.2 x 18.3mm (WHL), 3C Series
$156.55$156.55 -
Leuze
50137157
Polarized Retroreflective Sensor, 10-30VDC, 0.01-6m Range Limit with Reflector TK(S) 100x100, Red LED, 633nm, Push-Pull, Light (PNP/Dark (NPN) + Dark (PNP)/Light (NPN) Switching, 0.2m Cable M8 Connector, 11.4 x 34.2 x 18.3mm (WHL), IP67/69K
$184.90$184.90 -
Leuze
50136263
Polarized Retroreflective Sensor, 10-30VDC, 0.5m Range Limit, Autocollimation, Red Laser, 655nm, NPN, Light/Dark, LED, Teach Button, 2m Black PUR 4-Wire Cable, 11.4 x 34.2 x 18.3mm (WHL), PC-ABS with PMMA Lens, ECOLAB, -40 to +55C, IP67/69K
$366.70$366.70 -
Leuze
50136253
Polarized Retroreflective Sensor, 10-30VDC, 0.5m Range Limit, Autocollimation, Red Laser, 655nm, NPN, Light/Dark, LED, Teach Button, M8 Male 4-Pin Connector, 11.4 x 34.2 x 18.3mm (WHL), Red PC-ABS/PMMA Lens, ECOLAB, -40 to +55C, IP67/69K
$371.84$371.84 -
Leuze
50133701
Polarized Retroreflective Sensor, 10-30VDC, 0.5m Range Limit, Autocollimation, Red Laser, 655nm, PNP, Light/Dark, LED, Teach Button, 0.2m Cable M8 Connector, 11.4 x 34.2 x 18.3mm (WHL), PC-ABS with PMMA Lens, ECOLAB, -40 to +55C, IP67/69K
$379.03$379.03 -
Leuze
50133700
Polarized Retroreflective Sensor, 10-30VDC, 0.5m Range Limit, Autocollimation, Red Laser, 655nm, PNP, Light/Dark, LED, Teach Button, 0.2m Cable M12 Connector, 11.4 x 34.2 x 18.3mm (WHL), PC-ABS with PMMA Lens, ECOLAB, -40 to +55C, IP67/69K
$379.03$379.03
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
