Pepperl+Fuchs
267075-100526
Photoelectric LED Triangulation Sensor with Background Suppression, Non-Cancellable, No Returns
$168.00$168.00 -
Pepperl+Fuchs
216895
Photoelectric Sensor, Background Suppression, 10-30VDC, 4 Pin M8 Connector, Light On, PNP, Non-Metallic, IP57, Visible Red Beam, ML100 Series
$182.56$182.56 -
Pepperl+Fuchs
267075-100522
Photoelectric LED Triangulation Sensor with Background Suppression, Returns of This Item Must Be Approved by Manufacturer
$155.68$155.68 -
IDEC
SA2E-BP3C
Miniature Photoelectric Sensor with Background Suppression (BGS), 10-350mm/20-350mm Adjustable Sensing Range, Red LED, PNP, Light On/Dark On (Selectable), M8 4-Pin Connector, IP67, 10.8 x 19.5 x 31.5mm (WDH) Excluding LEDs and Controls
$89.29$89.29 -
IDEC
SA2E-BN3C
Miniature Photoelectric Sensor with Background Suppression (BGS), 10-350mm/20-350mm Adjustable Sensing Range, Red LED, NPN, Light On/Dark On (Selectable), M8 4-Pin Connector, IP67, 10.8 x 19.5 x 31.5mm (WDH) Excluding LEDs and Controls, NCNR
$89.05$89.05 -
$912.40$912.40 -
Pepperl+Fuchs
267075-100225
Photoelectric Laser Diffuse Mode Triangulation Sensor with Adjustable Background Suppression, Returns of This Item Must Be Approved by Manufacturer
$230.72$230.72 -
Pepperl+Fuchs
267075-100237
Photoelectric Laser Diffuse Mode Triangulation Sensor with Adjustable Background Suppression, Returns of This Item Must Be Approved by Manufacturer
$230.72$230.72 -
Pepperl+Fuchs
267075-100503
Photoelectric LED Triangulation Sensor with Background Suppression, Returns of This Item Must Be Approved by Manufacturer
$155.68$155.68 -
Pepperl+Fuchs
267075-100504
Photoelectric LED Triangulation Sensor with Background Suppression, Returns of This Item Must Be Approved by Manufacturer
$155.68$155.68 -
Pilz
Z9000039
Photoelectric Sensor, Diffuse Reflective With Background Suppression, 30-100mm Sensing Distance, 10-33VDC, Positive-Switching Semiconductor Outputs, M8 4-Pin Male, IP67
$309.71$309.71
Photoelectric sensors detect the distance, absence or presence of an object. These sensors are great for sensing long distances and detecting most materials.
How Does a Photoelectric Sensor Work?
Generally a photoelectric sensor consists of the following:
- Transmitter - emits the light beam
- Receiver - detects the light beam and converts it to an electrical signal
Photoelectric sensors detect changes in the light beam caused by the presence/absence, movement or properties of an object.
Types of Photoelectric Sensors:
- Through-Beam (Thru-Beam)
- Transmitter and receiver are two separate units that are directly opposite of each other. The sensor detects when an objects breaks the light beam
- Great for long distance detection
- Ideal for conveyors, counting or monitoring door openings
- Retroreflective (Reflective Mode)
- Transmitter and receiver are in one housing; light beam is reflected back by a reflector. Detection is triggered when an object breaks the beam.
- Medium range detection and easier to install than a through beam
- Ideal for package detection and pallet positioning
- Diffuse (Proximity Mode)
- The transmitter and receiver in one housing; the sensor detects light reflected directly off the target object (no reflector needed)
- Best for short range applications
- Ideal for detecting objects on assembly lines, verifying presence or checking fill level
- Specialized Types:
- Background Suppression: Can ignore objects beyond a set distance, focuses close range
- Color or Contrast Sensors: Detects specific colors or contrast differences
- Distance Measuring Sensors: Mesaure the distance to an object
Categories Related to Photoelectric Sensors:
- Stack lights - signal towers visually communicate the data or alerts that the photoelectric sensors are generating
- Smart relays - photoelectric sensors provide input signals which can process the data and control outputs
- Pushbuttons and estops - if your sensor detects a fault, an operator can use a pushbutton to reset the system
- HMIs - HMIs can dispay the data from the photoelectric sensor which allows you to monitor processes
