Bonfiglioli

1004100300004

VF 44 N 7 HS B3 VV, VF44N7HSB3VV

Right Angle Worm Reducer, VF44N7HSB3VV, Size 44, 55Nm/487 lb-in Size Rating, 7:1 Ratio, Metric Solid Input Shaft, Foot Mount Input Bottom, Ø18mm H7 Output Shaft, B3 Mounting Position

Bonfiglioli

200450271

VF 44 F1 70 P63 B5 B3, VF44F170P63B5B3

Right Angle Worm Reducer, VF44F170P63B5B3, Size 44, 55Nm Size Rating, 70:1 Ratio, IEC 63 Motor Adapter, B5 Large Motor Flange, Standard Flange Side 1, 110x87x60mm Output Flange, Ø18mm H7 x 64mm Hollow Output Shaft w/Keyway, B3 Mounting Position

Bonfiglioli

2G247090510001

W 75 UFCR2 D30 15 P90 B5 B3, W75UFCR2D3015P90B5B3

Right Angle Worm Reducer w/Universal Housing, W75UFCR2D3015P90B5B3, Frame Size 75, 320Nm Size Rating, 15:1 Ratio, IEC 90 Motor Adapter, B5 Large Motor Flange, Reduced Length/Diameter Flange Side 2, Ø30mm H7 Output Shaft Bore, B3 Mounting Position

Bonfiglioli

2006802180004

VF 49 P1 28 P80 B14 B3 PV, VF49P128P80B14B3PV

Right Angle Worm Reducer, VF49P128P80B14B3PV, Size 49, 90Nm Size Rating, 28:1 Ratio, IEC 80 Motor Adapter, B14 Small Motor Flange, Side Cover Shaft Mount Side 1, Ø25mm H7 x 82mm Hollow Output Shaft w/Keyway, B3 Mounting Position, Viton Oil Seals

Bonfiglioli

1G28010601008

W 86 U 10 HS B3 RB, W86U10HSB3RB

Right Angle Worm Reducer w/Universal Housing, W86U10HSB3RB, Frame Size 86, 440Nm/3890 lb-in Size Rating, 10:1 Ratio, Double Extended Metric Solid Input Shaft, Ø35mm H7 Output Shaft, B3 Mounting Position

Bonfiglioli

2006800630051

VF 49 P1 10 19/140 B3 PV

UNIVERSAL WORM GEAR BOXES - VF 49 P1 10 19/140 B3 PV Shaft mounted, Hollow output shaft with keyway, Output shaft dim.(dxl)= 25x82 mm, VITON OIL SEALS.

Bonfiglioli

2G320436I1

W 110 UFC1 100 P90 B14 B3, W110UFC1100P90B14B3

Right Angle Worm Reducer w/Universal Housing, W110UFC1100P90B14B3, Frame Size 110, 830Nm/7346 lb-in Size Rating, 100:1 Ratio, IEC 90 Motor Adapter, B14 Small Motor Flange, Reduced Length Flange Side 1, Ø42mm H7 Output Shaft, B3 Mounting Position

Bonfiglioli

LC90210S450001

Planetary gear LC Low backlash 090 2 20 STD 80A1 CD 14 KE

Bonfiglioli

TRC2012S000C

Planetary gear TR Low backlash 080 2 12 STD 70B1 CD 19 S1 VA SB KE Anglebacklash 5' Type of motor coupling clamping device Continuous service Vertical mounting positionmotor up Output shaft support Output shaft with keyway Customs Code: 848340

Bonfiglioli

2G28010671

Right Angle Worm Reducer w/Universal Housing, W86U10P112B5B3, Frame Size 86, 440Nm/3890 lb-in Size Rating, 10:1 Ratio, IEC 112 Motor Adapter, B5 Large Motor Flange, Ø35mm H7 Output Shaft, B3 Mounting Position

Bonfiglioli

1G20013001008

W 63 U 80 HS B3 KA, W63U80HSB3KA

Right Angle Worm Reducer w/Universal Housing, W63U80HSB3KA, Frame Size 63, 200Nm/1770 lb-in Size Rating, 80:1 Ratio, Metric Solid Input Shaft, Ø25mm H7 Output Shaft, B3 Mounting Position

Bonfiglioli

M00480210045

VF 44 P1 46 P63 B5 B3

Gearmotor, VF 44 P1 46 P63 B5 B3 Shaft Mounted, Hollow Output Shaft with Keyway, Output Shaft Dimensions (dxl)= 18x64 mm, IEC BN Motor 63B 4 230/460-60 IP55 CLF B5 CUS, "Pn= 0,18 KW" Voltage 230/460V 60Hz
