ARK-2250L-U3A2

Features Include:

• Input Voltage Supply: 12 VDC (9 ~ 36 VDC as option)
• Power Adaptor: AC to DC, DC12V/5A, 60 W (Optional)
• Power Consumption: Typical 6.92 W, Max. 41.72 W
• Socket: 1 x 260-Pin SO-DIMM
• Graphics Controller: Intel HD Graphics 520
• Graphics Engine: DirectX 11.3, OpenGL 4.4, and OpenCL 2.1, Full AVC/VC1/MPEG2 HW Decode
• I/O Serial Port: 4 x RS-232/422/485 port, support auto-flow control
• I/O USB: 4 x USB 3.0, 2 x USB 2.0
• Storage HDD: Supports one SATA 2.5" HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 300 MB/s)
• Storage SSD: 1 x full size mSATA socket (CN15, shared with mPCIe)
• Construction: Aluminum housing
• Mounting: Din-Rail mounting, Desk/wall-mounting, VESA mounting
• Dimensions: 260 x 54 x 140.2 mm (10.24" x 2.13" x 5.52")
• Intel 6th Gen Intel® Core™ U-series (i3/i5/i7)
• VGA and HDMI dual display, option 3rd display for triple display
• 12V lockable DC jack power input
• 9-36V power module compatible with all-in-one ordering
• -20 ~ 60 °C extend temperature operating
• 2 x full size mPCIe expansion for WIFI/Cellular communication module
• 1 x full size mSATA and 1 x 2.5" SATA storage device
• Advantech iDoor module and ARK Plus module compatible
• No RED Certification

Technical Information:

• Advantech ARK-2250L A2 Modular Fanless Box PC Datasheet
• Advantech ARK-2250 Modular Fanless Box PC User Manual
• Advantech ARK-2250 Modular Fanless Box PC Mounting Dimensions
