$124.95
Available Now!
Available Now!
(1 in stock)
IR-DQ16-P
Alt: iR Series
$124.95
Remote I/O, Digital Output Point: 16/Type Source
- Minimum Purchase:
- 1 unit
Description
The iR series are remote I/O that are available as Fieldbus coupler, analog (iR-A),digital (iR-D) or temperature options..
Features Include:
- Number of Outputs: 16
- Output Logic: Source
- Current Consumption: 196mA @ 5VDC
- Output Voltage: 11 ~ 28VDC
- Output Current: 0.5A per channel (Max. 4A)
- Dimensions (W x H x D): 27 x 109 x 81 mm
- Mount: 35mm DIN rail mounting
