Weg
-
SSW070255T5SH1Z
Alternate Part Number:
11043354, This is the Recommended Replacement for SSW070255T5SZ (11250177)
$2,804.78
In stock
Soft Starter, 255A, 3 Phase, 220?-575VAC Power Supply, Frame Size 4, IP00, 120VAC Auxiliary Cooling Fan, Certifications: UL, CE, CS, IRAM and C-TICK, Series SSW07, Please review and verify specifications for your application.
| Part Number | SSW070255T5SH1Z |
|---|---|
| SKU | SSW070255T5SH1Z |
| Alternate Part Number | 11043354, This is the Recommended Replacement for SSW070255T5SZ (11250177) |
| Weight - lbs. | 41.900000 |
| Base Unit of Measure | Each |
| Horsepower | See Spec |
| Voltage | 220 to 575VAC |
| Warranty | See Spec |
| Phase | See Spec or N/A |
| Options | No Special Options |
| Ratings | IP00 |
| Product Series | SSW07 |
| Amp Rating | 255 Amp |
| Availability | Please Contact Us |
| Manufacturer | Weg |
Features Include:
- Rated current: 255 A
- Power supply: 220-575 V
- Frame Size: 4
- Built-in bypass
- High starting duty
- Total control on the three phases
- Protection of the motor and built-in starter
- "Kick-Start" function for starting loads with high static friction
- Remote or local HMI (optional)
- Input for the motor PTC (optional)
- Operation in environments up to 55 °C
- Extremely reduced weights and dimensions
- RS-232, RS-485, DeviceNet or Ethernet communication (optional)
2023-03-11 00:19:19
Technical Information:
- Weg SSW070255T5SH1Z Datasheet
- Weg SSW07 Soft Starter Catalog
- Weg SSW07 Soft Starter Quick Start Guide
- Weg SSW07 Soft Starter User Manual
- Weg SSW07/08 Soft Starter Serial Communication Manual
- Weg SSW07 Soft Starter Programming Manual
- Weg Soft Starter General Training Guide
- WEG LV Variable Frequency Drives and Soft Starters 2020 Catalog
- Warranty Terms for Weg Automation Products
- 'Extend to a 3 Year Warranty' Form
