IDEC's high performance HMI's offer a higher display resolution, wider operating temperatures, more memory space and an extra video input. The HG*V-V series replaces the HG2G/HG3G/HG4G series (they will be discontinued March 2020).
Featuring up to 800 cd/m brightness, 1024 x 768 pixels high resolution displays, and over 100,000 hours of backlight life, they are the brightest, longest-lasting displays on the market.
A wide operating temperature range of -20°C to +60°C as well as IP66F, IP67F, Type 4X, 12, 13, and Class I Div 2 approval ratings, assures reliable operation in the toughest environments.
These touchscreens are built for endurance and are backed by an industry leading three-year warranty
Marshall Wolf Automation is your authorized IDEC distributor.
Features include:
High Resolution Display: 1024 x 768 pixels (8.4", 10.4", 12.1", 15"), 640 x 480 pixels (5.7")
Backlight light of 100,000 hours with up to 800 cd/m2 brightness
Wide range of Operating Temperature: -20˚C to +60˚C
Multiple Protocols - up to 4 protocols simultaneously
Remote Access, Monitor and Control Function
FTP, Email, Mobile App and Custom Web Page
Audio and Video Interface (8.4", 10.4", 12.1", 15")
Supports Analog and Discrete I/O Expansion Modules
IP66F/67F, Type 4X, 12 and 13, Class I Div 2
3 Year Warranty
Features Include:
LCD Type: TFT
Operating Voltage: 24VDC
Color Depth: 65,536 colors
Mounting: Portrait or landscape
Display Resolution: 1024 x 768 pixels
Brightness: 650 cd/m2
Wide Operating temperature range: -20°C to +60°C
USB Port: 1 Type A & 1 mini-B
Backlight lifespan: 100,000 hours min
FTP, Email, Web Server and BACnet Protocol
WindEDIT Mobile App for iOS and Android
Multiple protocols - up to 4 protocols simultaneously
