Weg
-
GPH2007PC2000
Alternate Part Number:
Combination Soft Starter
$2,499.84
In stock
Soft Starter, 7.5hp, 24A, 3 Phase, 230VAC, NEMA 4/12 Enclosure with Ext. AC3 Bypass with Circuit Breaker, No Keypad
Combination soft starter that only requires input power and output motor connections!
Looking for quick installation and easy start up?
Our WEG GPH2 is a combination soft starter that requires only input power and output motor connections!
Check individual models for these options:
- AC3 by-pass contactor and DOL selector switch
- Door mounted keypad
- 575V AC supply
- SUSE service entrance rated
The GPH2 is great for centrifugal pumps, screw compressors, centfigual fans, wood chippers, lathes, saws and conveyors.
Ideal when used with WEG motors!
| Part Number | GPH2007PC2000 |
|---|---|
| SKU | GPH2007PC2000 |
| Alternate Part Number | Combination Soft Starter |
| Weight - lbs. | 140.000000 |
| Base Unit of Measure | Each |
| Horsepower | 7.5 hp |
| Voltage | 220/240VAC |
| Warranty | 18 Months |
| Phase | Three Phase |
| Options | Built-In Bypass, For Centrifugal Pumps |
| Ratings | NEMA 4 , NEMA 12 |
| Product Series | GPH2 Series |
| Amp Rating | See Spec |
| Availability | Please Contact Us |
| Manufacturer | Weg |
Features Include:
- Rated for 300% for 30 seconds 4 x per hour
- 5 - 500HP at 230V
- 10 – 1200hp at 460V
- Wall mounted enclosures for SSW07 (from 17 - 200Amps) NEMA12
- Floor Mounted enclosure for SSW06 (from 255A – 800A) NEMA12
Standard Panel Includes:
- Soft Starter:
- SSW07 for GPH2 from 17 to 200A (all models with integrated AC1 by-pass)
- SSW06 for GPH2 from 255 up to 800A (all models with integrated AC1 by-pass)
- Circuit Breaker Through Door Disconnect
- Control Power Transformer
- Start/Stop pushbuttons
Optional Features:
- AC3 by-pass contactor and with Soft Starters and DOL Selector Switch
- Door mounted keypad
- NEMA 3R Enclosure
- NEMA 4 Enclosure
- Rain/Sun Shield for Outdoor Installation
- 575V
Applications:
- Centrifugal Pumps
- Screw Compressors
- Wood Chipper
- Veneer Lathe
- Saws
- Conveyors
