PLDS-202-RY

The PLD series is a 25mm LED light tower with an aluminum body. This series has a built-in direct mounting pole installed and lead wire connection. Available in steady or steady/flashing (F), this series is available in 1 to 5 lights in either 12VAC/DC (01) or 24VAC/DC (02). A -W on the end of the part number means the lenses are clear until the light is activated.

Features Include:

• Operation/Function: Steady/Flashing
• Material: Body: Aluminum, Lid: ABS, Lens: PC, Fixing bolt: Aluminum, Lock nut: steel
• Flash Rate: Approx. 80 ± 5 flashes/min.
• Ambient Temperature: -15 ~ 40 °C
• Storage Temperature: -20 ~ 70°C
• Vibration: 3mm at 10~55Hz
• Well suited for small device applications
• Long LED life and reliable operation
• Prism-cut lenses for even light distribution
• Direct mounting pole installed
• Lead wire connection

Technical Information:

• Menics PLD Series Light Tower Datasheet
• Menics Light Tower Mounting Option Datasheet
• Menics PLD Series Light Tower User Manual
